Wet Area for Archicad - Fast and Compliant Wet Areas

Wet Area

Eliminate the need for manual fall calculations—this intelligent tool provides live feedback as you draw, displaying falls in metric or imperial units and checking compliance against your custom minimum and maximum fall settings. Positioning the floor waste or drain has never been easier—simply drag it to suit your required falls and fixtures, and watch the gradients update in real time.

Prefer automation? Just set your minimum and maximum allowable falls, and the tool will automatically adjust perimeter levels to ensure compliance.

The Wet Area tool adapts to any bathroom shape, with unlimited perimeter points to accommodate angled walls and riser intrusions.

Paired with Archibites Model View Options, you can easily generate floor plans, finish plans, and concrete setout drawings—each with tailored graphics and accurate setdown level adjustments.

Tested Archicad compatibility: 25, 26, 27, 28

Product Version

License Type

Clear

Intelligent Construction

Construct Wet Areas/Rooms using different fall types and set to desired shape.

Single Point Fall
Single Linear Fall
Opposing Linear Falls
Stretch and create unlimited perimeter points for any shaped room
Set Floor Drain level and Perimeter level
Select desired floor waste shape and rotate as needed
All falls update as floor drain/waste is moved
Maintain desired Perimeter level or set levels to update as floor drain or perimeter changes based on rules

Archicad built-in

No equivalent. Can be acheived through use of mesh, lines, text and a calculator to check falls!
Time consuming and cumbersome.

Rules Based

Use rules to highlight or update for compliance

Set Floor Drain and Perimeter level
Set minimum and maximum falls for crossfalls, linear falls and perpendicular falls (shortest fall to perimeter)
Choose how rules are applied – Highlight non-compliant falls maintining perimeter level or
Automatically update perimeter level to comply
Input rules by ratio, angle, percentage or per foot.

3D Display & Section

Display options 3D

Turn on/off
Select to display either or all Finish, Mortar or Concrete
3D Pens, Building Materials and Surfaces each Finish and Substrate
Section Pens and Fills take on Building Material settings

Floor Plan Display

Control what is shown depending on drawing type

Floor Plan: Finish
Concrete Setout: Base of Mortar with falling setdown, or
Concrete Setout: Base of Mortar as flat setdown, and
Either of the above by Model View Options
Elevation Levels adjust depending which finish or substrate is shown.
Measure Elevation Level from Base, Waste/Drain, Home Storey, Project Zero, 1st/2nd Reference, Sea Level Point
Select Text anchor or let object automatically choose best fit inside or outside perimeter.

Full Graphical control
